Description
The DormaKaba E-Plex 5700 mortise prox lock is a Grade 1 electronic access control solution designed for high-security commercial applications. It supports up to 3,000 access codes and logs 30,000 audit events, making it ideal for facilities requiring detailed access tracking and multi-user management without traditional keys.
This mortise lock features Schlage FSIC prep and accepts Schlage cores (sold separately). Installation requires standard mortise preparation; the satin chrome, extra heavy-duty construction suits indoor and outdoor use. As an authorized DormaKaba dealer, E.D. Locks offers expert guidance on configuration, keying, and integration. Contact sales@edlocks.com or call 1-877-207-6067 for assistance selecting the right core and exit device trim for your application.
Specifications
- Grade: 1 (Extra Heavy-Duty)
- Lock Type: Mortise
- Access Codes: Up to 3,000
- Audit Events: 30,000
- Backset: 2 3/4" (70 mm)
- Latches: 3/4" (19 mm) latch, 1" (25 mm) deadbolt (optional)
- Finish: Satin Chrome
- Construction: Solid cast housings, solid cast zinc levers
- Cylinder: Schlage FSIC Prep, less core
- Handing: Non-handed, field-changeable
