Description
The DormaKaba E5766XKWL-626-41 is a Grade 1 mortise proximity lock designed for high-security applications in commercial and institutional facilities. It supports up to 3,000 access codes and logs 30,000 audit events, making it ideal for organizations that need detailed access tracking and user management without complex infrastructure.
This lock is compatible with Kaba 90 keyway cylinders and features non-handed, field-reversible installation for both left and right-hand doors. The 2 3/4 inch mortise backset and satin chrome finish suit standard commercial openings. As an authorized DormaKaba dealer, E.D. Locks offers expert configuration assistance and system support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for help selecting the right access control solution.
Specifications
- Grade: 1 (Extra heavy-duty)
- Lock Type: Mortise Proximity
- Finish: Satin Chrome
- Access Codes: 3,000 maximum
- Audit Events: 30,000 maximum
- Keyway: Kaba 90
- Backset: 2 3/4 inch (70 mm)
- Latch Options: 3/4 inch (19 mm) or 1 inch (25 mm) deadbolt
- Handing: Non-handed, field-reversible
- Housing: Solid cast zinc
- Application: Indoor and outdoor
