Description
The Von Duprin EL33ANL 4 313 RHR is a UL-listed panic exit device designed for single and double doors with mullion. Built to ANSI A156.3 Grade 1 standards, it features a grooved case mechanism and deadlocking latch bolt with 3/4 inch throw. Ideal for commercial facilities requiring reliable emergency egress hardware.
This rim-mounted device fits door sizes from 2'4" to 4', and is non-handed except when the signal switch option is selected. Compatible with wood and metal doors, the EL33ANL ships with sex bolts and standard hex key dogging. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on configuration, installation, and keying options tailored to your building's needs.
Specifications
- Model: EL33ANL 4 313 RHR
- Brand: Von Duprin
- UL Listed Panic Exit Hardware
- ANSI A156.3 ± 2014 Grade 1
- Case Type: Grooved Mechanism Case
- Device Lengths: 3' (711-914mm); 4' (864-1219mm)
- Latch Bolt: Deadlocking, 3/4" (19mm) throw
- Center Case Dimensions: 8 3/16" x 2 13/32" x 1 9/16" (208mm x 62mm x 40mm)
- Mechanism Case Dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
- Pushbar Projection (Neutral): 3 13/16" (97mm)
- Pushbar Projection (Depressed): 3 1/16" (78mm)
- Device Centerline from Finished Floor: 39 13/16" (1011mm)
- Dogging: Hex key standard; CD Cylinder or LD Less Dogging options available
- Electric Options: LX Latchbolt Monitor, RX Pushpad Monitor, RX2 Double Pushpad Monitor, SS Signal Switch, EL Electric Latch Retraction, ALK Alarm Exit Kit
- Strike: 1439 Dull Black
- Compatible with: Wood and Metal Doors
- Fasteners: Sex Bolts SNB 1 3/4" - 2 1/4" (44mm - 57mm)
