Description
The Von Duprin EL33ANL-OP 3 313 is a UL-listed panic exit device designed for single and double doors with mullion. Built to ANSI A156.3:2014 Grade 1 standards, it provides reliable emergency egress for commercial facilities, schools, hospitals, and multi-tenant buildings where life safety code compliance is essential.
This rim-mounted device fits door sizes from 2 feet 4 inches to 4 feet and accepts multiple electric monitoring and latch retraction options. Available with standard hex key dogging or optional cylinder dogging. E.D. Locks is an authorized Von Duprin dealer offering expert configuration assistance and access to the full range of compatible outside trim and function options. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for application guidance.
Specifications
- Model: EL33ANL-OP 3 313
- Grade: ANSI A156.3:2014 Grade 1
- Device Lengths: 3 feet (711-914mm) and 4 feet (864-1219mm) door sizes
- Latch Bolt: Deadlocking, 3/4 inch throw
- Center Case Dimensions: 8 3/16 x 2 13/32 x 1 9/16 inches (208 x 62 x 40mm)
- Mechanism Case Dimensions: 2 1/4 x 2 1/4 inches (57 x 57mm)
- Device Centerline from Floor: 39 13/16 inches (1011mm)
- Pushbar Projection (Neutral): 3 13/16 inches (97mm)
- Pushbar Projection (Depressed): 3 1/16 inches (78mm)
- Dogging: Hex key standard; CD cylinder or LD less dogging options available
- Electric Options: LX latchbolt monitor, RX/RX2 pushpad monitor, SS signal switch, EL electric latch retraction, ALK alarm exit kit
- Strike: 1439 dull black
- Sex Bolts: 1 3/4 to 2 1/4 inches for wood and metal doors
- Non-handed (except with SS signal switch option)
