Description
The Yale 8800 Series JNR8818-2FL mortise lock delivers ANSI/BHMA Grade 1 security for demanding commercial applications. Featuring a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and UL/cUL fire rating up to 3 hours, this lock provides uncompromising strength and durability. Field-reversible design and quick lever handing simplify installation on doors up to 3-1/4" thick.
This mortise lock is compatible with standard 1-3/4" doors and includes a 6-pin keyed-random cylinder with two keys. The stainless steel latchbolt and free-floating bevel front accommodate various door conditions. Contact our team at sales@edlocks.com or 1-877-207-6067 for keying assistance, finish selection from 17 options, or upgrade guidance from an authorized Yale dealer.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- Fire Rating: UL/cUL up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" to order)
- Cylinder: 6-pin brass, keyed-random with two keys (7-pin available)
- Strike: 1-1/4" curved lip, reversible (other lengths to special order)
- Finish: 17 finishes available
- Warranty: 10 years mechanical
