Description
The Yale 8800 Series mortise lock delivers uncompromising strength and durability for commercial applications requiring ANSI/BHMA Grade 1 security. This heavy-duty lock features a reinforced stainless steel deadbolt, vandal-resistant trim, and UL/cUL fire rating up to 3 hours, making it ideal for high-traffic institutional and commercial buildings.
Installation is straightforward with quick lever handing, field-reversible latchbolt, and standard nonhanded strike. Available in 17 finishes and compatible with standard 1-3/4" doors (thicker doors available to order). As an authorized Yale dealer, E.D. Locks offers expert guidance on specification, finish selection, and keying options. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- Certification: ANSI/BHMA A156.13 Series 1000, Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available)
- Front: Bevel front, free-floating (flat to 1/8" bevel adjustment)
- Cylinder: Brass, 6-pin keyed-random with 2 keys (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" doors (reversible)
- Reversibility: Field reversible handing
- Finishes: 17 available
- Warranty: 10 years mechanical
