Description
The Yale 8800 Series mortise lock delivers commercial-grade security for interior and exterior doors in offices, hotels, and institutions. This ANSI/BHMA Grade 1 certified lock features a reinforced stainless steel deadbolt, vandal-resistant trim, and a 3/4-inch stainless steel throw, solving the need for durable, tamper-proof access control in high-traffic environments.
Compatible with standard 1-3/4-inch doors and field-reversible for left or right hand installation. The lock includes a 6-pin keyed-random cylinder with two keys and fits standard mortise prep. As an authorized Yale dealer, E.D. Locks provides expert configuration assistance and access to all 17 finish options. Contact sales@edlocks.com or 1-877-207-6067 for keying, handing, or compatibility questions.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4 inch
- Latchbolt: 3/4 inch stainless steel throw
- Door Thickness: 1-3/4 inch standard
- Cylinders: Brass, 6-pin keyed-random with two keys
- Reversibility: Field reversible handing
- Strikes: 1-1/4 inch curved lip for 1-3/4 inch door
- Finishes: 17 available options
- Warranty: 10 year mechanical
