Description
The Schlage L9040 07L 613 is an extra heavy-duty mortise lock engineered for high-traffic commercial environments including schools, hospitals, and factories. Built to ANSI Grade 1 standards, it withstands constant use and abuse with a heavy-gauge steel case, all-metal zinc dichromate-plated components, and two-piece anti-friction tongue for reduced wear.
This universal lock case accommodates ten functions in one body and features field-reversible handing without opening the case, simplifying installation and retrofits. Compatible with standard mortise lock applications and beveled door edges. As an authorized Schlage dealer, E.D. Locks provides expert guidance on specification, keying, and installation. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for technical support.
Specifications
- Series: Schlage L-Series
- Model: L9040 07L 613
- Grade: ANSI Grade 1
- Case Material: Heavy-gauge wrapped steel
- Plating: Zinc dichromate on working parts
- Functions: Ten functions in universal lock case
- Handing: Field-reversible
- Security Features: Break-away spindle, hub blocking plate, spring-loaded fusible link for fail-secure fire mode
