Description
The DormaKaba Simplex LR1076B-03-41 is a heavy-duty mechanical pushbutton lock designed for facilities needing keyless access control between public and private areas. No keys, cards, computers, or batteries required. Change combinations in seconds without removing the lock, making it ideal for offices, schools, hospitals, and secure storage areas.
This cylindrical lock installs on wood or metal doors with standard ASA 161 preparation and fits door thicknesses from 1⅜ inch to 2¼ inch. Factory-handed with a ½ inch throw latch (¾ inch optional), ADA-compliant fixed levers, and 3-hour UL/ULC fire rating. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert specification review, handing selection, and installation support.
Specifications
- Brand: DormaKaba
- Model: LR1076B-03-41
- Lock Type: Mechanical pushbutton cylindrical
- Door Thickness: 1⅜ inch (35 mm) to 2¼ inch (57 mm)
- Pre-assembled for: 1⅝ inch (41 mm) to 2 inch (51 mm) doors
- Backset: 2¾ inch (70 mm) or 2⅜ inch (60 mm)
- Latch Throw: ½ inch (13 mm) standard; ¾ inch (19 mm) optional
- Door Preparation: ASA 161 with through holes
- Handing: Factory-handed; not field reversible
- Strike: Standard or ASA strike plate
- Levers: Fixed ADA-compliant
- Keypad: Vandal-resistant solid metal pushbuttons
- Accessibility: ADA compliant
- Durability: D.O.D. Compliant 5220.22M
- Fire Rating: 3-hour UL/ULC for "A" labeled doors
- Weather Resistant: Yes
- Warranty: 3 years
- Minimum Stile: 5 inch (127 mm) recommended
