Description
The Schlage LV9070L is a heavy-duty mortise lock built for high-traffic commercial environments like schools, hospitals, and factories. This ANSI Grade 1 certified lock delivers dependable security and operation under constant use, featuring a fully wrapped steel case, all-metal zinc dichromate-plated parts, and anti-friction components that reduce wear.
The LV9070L accommodates multiple functions in one universal case and accepts standard Schlage cylinders. Installation is straightforward with field-reversible handing and external spring cages for simple trim retrofit. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on cylinder keying, function selection, and compatibility with your door prep.
Specifications
- Grade: ANSI Grade 1
- Series: L9000 Extra Heavy Duty
- Case: Heavy-gauge, fully wrapped steel with zinc dichromate plating
- Functions: Ten functions available in one case
- Handing: Field-reversible without opening lock case
- Security Features: Break-away spindle, hub blocking plate, spring-loaded fusible link (fail secure)
- Trim Mount: Thru-bolted, screwless inside lever shank
- Door Fit: Floating mounting tabs accommodate beveled edges
