Description
The Falcon MA441P SG 605 is a heavy-duty mortise lock engineered for high-traffic commercial environments including offices, hospitals, and educational facilities. This ANSI Series 1000 lock combines dependable security with interchangeable core technology, enabling fast re-keying without removing the lock body. Its two-piece stainless steel latch and saw-resistant roller deadbolt withstand constant use.
The MA441P accommodates door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset and ships with two nickel silver keys. It is reversible in the field and compatible with SFIC products. For expert guidance on keying options, handing, electrified functions, or installation, contact E.D. Locks at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: Falcon
- Model: MA441P SG 605
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyway: "G" standard (standard cylinder), "A" standard (I/C cylinder)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable
- Strike: Brass or stainless steel, non-handed
- Electrified Functions: 12 or 24 VDC available
- ANSI/BHMA: Series 1000 (ANSI/BHMA 156.13)
- UL: 3 hour A label
