Description
The Falcon MA921B mortise lock delivers commercial-grade security and durability for offices, hospitals, schools, and institutional facilities. Built to withstand heavy daily use, this Series 1000 lock combines dependable performance with an interchangeable core design that simplifies re-keying and maintenance.
The MA921B fits standard 1-3/8" to 2-1/2" door thickness and is compatible with SFIC products from other manufacturers. Available in electrified (12 or 24 VDC) or non-electric versions with multiple keyway and finish options. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on specification, keying, and installation.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5/6/7-pin standard or 6/7-pin interchangeable core
- Keyways: "G" standard (standard cylinder), "A" standard (I/C cylinder)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw with two 13/16" saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, non-handed, ANSI A115.1 compliant
- ANSI/BHMA: Meets 156.13, Series 1000
- UL: 3 hour A label
- Electrified: Available 12 or 24 VDC
