Description
The Falcon MA941P 626 is a heavy-duty mortise lock engineered for commercial environments including offices, hospitals, and educational facilities. Built with cold-formed steel construction and hardened steel hubs, it delivers dependable security and performance under constant use. The interchangeable core (SFIC) design enables quick re-keying without removing the lock body, making maintenance and updates fast and affordable.
This lock accommodates standard door thicknesses from 1-3/8 to 2-1/2 inches and features a 2-3/4 inch backset. It meets ANSI/BHMA 156.13 Series 1000 and carries a 3-hour UL label, making it suitable for high-security applications. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying options, finishes, and electrified configurations. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for compatibility and installation support.
Specifications
- Brand: Falcon
- Model: MA941P 626
- Lock Type: Mortise, Interchangeable Core (SFIC)
- Door Thickness: 1-3/8 to 2-1/2 inches
- Backset: 2-3/4 inches
- Case: Cold-formed steel, zinc dichromate plated, 0.090 inch thick
- Latch Bolt: Two-piece stainless steel, 3/4 inch projection
- Dead Bolt: 1 inch throw with saw-resistant rollers
- Faceplate: 1-1/4 x 8 inch, brass or stainless steel
- Cylinders: Solid brass, 5, 6, or 7-pin (6 or 7-pin on I/C)
- Handing: Right-hand standard; left-hand optional, reversible
- Finish Options: See Falcon finishes chart
- Electrified: 12 or 24 VDC available
- Certifications: ANSI/BHMA 156.13 Series 1000, UL 3-hour label
