Marks Metro Apartment Mortise Lockset 114 Series


$106.82
SKU:
114
In Stock & Ready To Ship!
Current Stock:Only left:

Description

Marks Metro Apartment Mortise Lockset 114 Series

Specifications

  • Thru-bolted knob/plate assemblies integrate and align with lock body.
  • Standard Finish: US 3
  • Exterior: Wrought brass, screwless round knob, 2-1/4" diameter on steel reinforced brass plate, 10" x 2-3/4". Two thru posts pass thru lock body. Integral spring-loaded 9/32" spindle.
  • Interior: Wrought brass, screwless round knob, 2-1/4" diameter on steel reinforced brass plate, 7" x 2-1/4". Exposed 8-32 mounting. Bolts engage outside plate assembly. Integral spring- loaded 9/32" spindle.
  • Cylinder: 5-pin cylinder, 1-1/8" long
  • Strike: Conforms to ANSI spec.A115.1, 4-7/8" x 1-1/4" x 3/32" thick, 5/8" curved lip
  • Door Thickness: 1-1/4" to 1-3/4"
  • Backset: 2-1/2"
  • Lock Front: 7-5/8" x 1-1/16", .187" thick, flat or 3° bevel, solid brass. Optional front: 8" x 1-1/4" steel backplate with brass cover plate.
  • Deadbolt: Cast brass, 1" throw
  • Latch: Solid brass, 1/2" throw, reversible
  • Rocker Switch: Locks or unlocks hub
  • Hubs: 9/32" on square with steel security separator
  • Hub Lock Arm: Steel, .125" thick
  • Case: High pressure cast Zamac, baked enamel finish
