Description
The Marks USA 7NY10A is a durable Grade 1 mortise lockset built for commercial doors requiring reliable security without fire-rated certification. Its high-pressure cast Zamac body with baked enamel finish resists corrosion, while the cast alloy 1-inch throw deadbolt provides strength. The flexible faceplate installs flat or at a 3-degree bevel, making it adaptable to various door preparations.
This lockset fits standard mortise openings and features a 2-3/4-inch backset with reversible installation. The MARKS 'C' keyway cylinder comes with 6-pin security and two keys. For proper installation and keying assistance, contact our experts at sales@edlocks.com or 1-877-207-6067. As an authorized dealer, we provide technical support and genuine parts to ensure your security hardware performs reliably.
Specifications
- Brand: Marks USA
- Model: 7NY10A
- Backset: 2-3/4 inches
- Deadbolt Throw: 1 inch cast alloy
- Latch Throw: 5/8 inch anti-friction
- Case Material: High-pressure cast Zamac with baked enamel finish
- Front: 1-1/4 inch x 8 inch, flat or 3-degree bevel
- Cylinder: MARKS 'C' keyway, 6-pin with 2 keys
- Hubs: 9/32 inch on square steel with security separator
- Exterior Dimensions: 10 inches H x 2-3/4 inches W
- Interior Dimensions: 7 inches H x 2-1/4 inches W
- Spindles: Independent spring-loaded captivated
- Installation: Reversible mortise lock, thru-bolted screwless assembly
