Description
The Yale 8800 Series mortise lock trim pack delivers ANSI/BHMA Grade 1 security for commercial doors. Designed for offices, retail, and institutional buildings, this heavy-duty lock combines a reinforced stainless steel deadbolt with vandal-resistant trim to prevent forced entry and unauthorized access on standard 1-3/4" doors.
Installation is straightforward with field-reversible handing, quick lever setup, and a standard nonhanded strike. The 6-pin keyed-random cylinder includes two keys. For compatibility verification, keying options, finish selection from 17 available finishes, or questions about heavier doors up to 3-1/4", contact our experts at sales@edlocks.com or 1-877-207-6067. As an authorized Yale dealer, we ensure proper specification and support.
Specifications
- ANSI/BHMA Certified: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Windstorm: Certified
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available to order)
- Fronts: Bevel front, free-floating, adjustable flat to 1/8" standard bevel
- Cylinders: Brass, 6-pin, keyed-random with two keys (7-pin available)
- Reversibility: Field reversible handing
- Strikes: 1-1/4" curved lip for 1-3/4" door standard
- Finishes: 17 available
- Warranty: 10 years mechanical
