Description
The Yale 8800 Series mortise lock trim pack delivers commercial-grade security for interior and exterior doors in offices, retail, and institutional buildings. Field-reversible handing, reinforced stainless steel deadbolt, and vandal-resistant trim make installation simple and performance reliable for high-traffic environments.
This ANSI/BHMA Grade 1 certified lock fits standard 1-3/4" doors and accommodates thicker doors by special order. Yale's authorized dealers provide expert sizing, keying, and finish selection assistance at sales@edlocks.com or 1-877-207-6067 to ensure the perfect fit for your application.
Specifications
- ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL/cUL fire rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door thickness: 1-3/4" standard, to 3-1/4" thick by special order
- Mechanism: Stainless steel
- Cylinders: Brass, 6-pin, keyed-random with two keys (7-pin available)
- Strikes: 1-1/4" curved lip for 1-3/4" door (other lengths available)
- Field reversible handing
- Available in 17 finishes
- Warranty: 10 years mechanical
