Description
The Yale 8800 Series mortise lock trim pack delivers commercial-grade security for interior and entrance doors. Designed for uncompromising strength, this ANSI/BHMA Grade 1 certified lock features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing. Ideal for offices, hospitals, schools, and multi-family buildings requiring heavy-duty, long-life performance.
The MOR8847FL trim pack fits standard 1-3/4" door thickness and installs easily with quick lever handing and a nonhanded strike. Yale mortise locks are backed by expert support from E.D. Locks, an authorized dealer offering free shipping on orders over $450. Contact our team at sales@edlocks.com or 1-877-207-6067 for keying assistance and compatibility questions.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" thick to order)
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available to order)
- Strike: 1-1/4" curved lip for 1-3/4" door, reversible
- Field Reversible: Yes
- Warranty: 10 year mechanical
