Description
The Yale 8864FL is a commercial-grade mortise lock built for high-security applications in offices, hospitals, and institutional buildings. This ANSI/BHMA Grade 1 certified lock features a reinforced stainless steel deadbolt, vandal-resistant trim, and UL/cUL fire rating up to 3 hours, delivering uncompromising strength and durability.
Field reversible with quick lever handing and standard nonhanded strike for flexible installation on 1-3/4" standard doors. Compatible with 6-pin keyed-random cylinders (two keys included). For expert guidance on specifications, finishes, or custom orders, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Certification: ANSI/BHMA A156.13 Series 1000, Grade 1
- Fire Rating: UL/cUL up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available to order)
- Front: Bevel front, free-floating 1/8" adjustment
- Cylinder: 6-pin brass, keyed-random (7-pin available)
- Reversibility: Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths to special order)
- Warranty: 10 year mechanical
- Finishes: 17 available
