Description
The Sargent 80 Series NB8746G is a heavy-duty exit device engineered for commercial and institutional facilities demanding maximum security and durability. This rim-mounted unit exceeds ANSI/BHMA Grade 1 standards and suits wood or metal doors 1-3/4" thick, making it ideal for schools, hospitals, offices and multi-tenant buildings requiring reliable emergency egress and tamper-resistant operation.
The NB8746G ETE LHR 32D configuration is pre-fitted for 32" door widths with no cutting required. Modular construction and minimal moving parts mean virtually maintenance-free performance over the building's lifetime. E.D. Locks carries factory-authorized Sargent hardware and our specialists at sales@edlocks.com or 1-877-207-6067 can verify compatibility, discuss optional delayed egress or alarmed features, and ensure proper installation for your specific application.
Specifications
- Brand: Sargent
- Series: 80 Series
- Model: NB8746G ETE LHR 32D
- Configuration: Rim-mounted, End-to-end rail
- Hand: Left-hand reverse
- Door Width: 32" (no cutting required)
- Door Thickness: 1-3/4" (44mm), wood or metal
- Minimum Stile: 4-1/2" (114mm) with trim; 3-1/2" (88mm) without trim
- Standards: ANSI/BHMA Grade 1
- Features: Modular construction, maintenance-free, options for delayed egress and alarmed exit
