Description
The Schlage ND50BD is a Grade 1 cylindrical lockset designed for commercial applications including healthcare, education, government, office and retail facilities. This non-handed lockset solves the need for reliable, code-compliant door security with extensive function and keying options that adapt to nearly any access control requirement.
Compatible with standard door thicknesses from 1 5/8" to 2 1/8", the ND50BD installs easily and features a 6-pin Everest 29 keyway with two keys per lock. As an authorized Schlage dealer, E.D. Locks provides expert installation guidance, keying assistance and access control support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for help selecting the right configuration and finish for your project.
Specifications
- Brand: Schlage
- Model: ND50BD RHO 626 EE212
- Grade: 1 (ANSI/BHMA certified)
- Operating Cycles: 3+ million without failure
- Handing: Non-handed
- Door Thickness: 1 5/8" to 2 1/8" (41mm-54mm)
- Backset: 2 3/4" standard (70mm); optional 2 3/8", 3 3/4", 5"
- Faceplate: 1 1/8" x 2 1/4" square corner, beveled
- Latch Bolt: Steel, 1/2" throw, deadlocking
- Cylinder: 6-pin Everest 29 S123 keyway
- Keys: Two patented nickel silver keys per lock
- Keying: Master keying, grand master keying, construction keying available
- Strike: ANSI curved lip, 1 1/4" x 4 7/8" x 1 3/16" standard
- Lock Chassis: Zinc plated
- Warranty: 10-year limited
