Description
The Schlage ND82PD RHO 626 is a Grade 1 cylindrical lockset engineered for commercial applications including healthcare, education, government, office and retail environments. It delivers proven reliability with non-handed installation, extensive keying options, and wire-wireless access control capabilities to meet modern security needs.
Fits standard door thickness of 1 5/8" to 2 1/8" with 2 3/4" backset and 6-pin Everest 29 keyway. Includes two nickel silver keys per lock and supports master keying and interchangeable core cylinders. As an authorized Schlage dealer, E.D. Locks provides expert installation guidance and ten-year warranty support. Contact sales@edlocks.com or 1-877-207-6067 for keying assistance or compatibility questions.
Specifications
- Brand: Schlage
- Model: ND82PD RHO 626 EE214
- Grade: 1 (3+ million cycle rating)
- Handing: Non-handed
- Door Thickness: 1 5/8" to 2 1/8" (41mm-54mm) standard
- Backset: 2 3/4" (70mm) standard; optional 2 3/8", 3 3/4", 5"
- Faceplate: 1 1/8" x 2 1/4" square corner, beveled
- Latch Bolt: Steel, 1/2" throw, deadlocking
- Cylinder: 6-pin Everest 29 S123 keyway
- Keys Included: Two patented nickel silver keys per lock
- Keying Options: Master keying, grand master keying, interchangeable core, Primus high security
- Strike: ANSI curved lip 1 1/4" x 4 7/8" x 1 3/16"
- Warranty: Ten-year limited
