Description
Yale's 8800 Series mortise lock trim pack delivers commercial-grade security for interior and exterior doors in offices, schools, and institutional buildings. The PBCN8801FL features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and ANSI/BHMA Grade 1 certification. Field-reversible latchbolt and quick lever handing simplify installation on standard 1-3/4" doors.
This trim pack includes a 6-pin keyed-random cylinder with two keys, adjustable bevel front, and a reversible curved lip strike. Fits doors up to 3-1/4" thick. Available in 17 finishes with a 10-year mechanical warranty. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for finish selection, keying options, and expert installation guidance from an authorized Yale dealer.
Specifications
- ANSI/BHMA A156.13 Grade 1 certified
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Standard door thickness: 1-3/4" (up to 3-1/4" to order)
- Cylinder: Brass, 6-pin keyed-random (7-pin available)
- Strikes: 1-1/4" curved lip for 1-3/4" door (other lengths special order)
- Finishes: 17 available
- Warranty: 10 years mechanical
