Description
The Yale 8800 Series mortise lock trim pack is engineered for commercial doors requiring ANSI/BHMA Grade 1 security and durability. Built with reinforced stainless steel deadbolts and heavy-duty, vandal-resistant trim, this lock suits high-traffic entrances, office buildings, and institutional applications where strength and reliability matter.
The PBR8805FL accommodates doors 1-3/4" to 3-1/4" thick with field-reversible handing and a standard 2-3/4" backset. It ships with a brass 6-pin cylinder and two keys. An authorized E.D. Locks dealer can verify finish options, keying, and compatibility with your door preparation. Contact our experts at sales@edlocks.com or 1-877-207-6067 for installation guidance.
Specifications
- ANSI/BHMA A156.13 Series 1000, Grade 1 certified
- UL/cUL fire-rated up to 3 hours
- Windstorm certified (refer to local codes)
- Mechanism: stainless steel
- Backset: 2-3/4" standard
- Latchbolt: 3/4" stainless steel throw
- Door thickness: 1-3/4" standard, to 3-1/4" to order
- Cylinder: brass, 6-pin, keyed-random with two keys; 7-pin available
- Strikes: 1-1/4" curved lip for 1-3/4" door standard, reversible
- Finishes: 17 available
- Warranty: 10 years mechanical
