Description
The Yale 8800 Series mortise lock trim pack is a heavy-duty commercial entrance solution for institutional and commercial buildings requiring ANSI/BHMA Grade 1 security. It features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing for flexible installation on doors 1-3/4" to 3-1/4" thick.
This trim pack suits standard 2-3/4" backset applications and works with 6-pin keyed-random cylinders (7-pin available). UL/cUL fire-rated up to 3 hours and windstorm-certified. As an authorized Yale dealer, E.D. Locks provides expert pre-sale guidance and 10-year warranty support. Contact sales@edlocks.com or call 1-877-207-6067 for finish selection and compatibility questions.
Specifications
- Brand: Yale/Accentra
- Series: 8800
- Certification: ANSI/BHMA A156.13 Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard, to 3-1/4"
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available)
- Strikes: 1-1/4" curved lip for 1-3/4" doors (reversible)
- Reversibility: Field reversible handing
- Finishes: 17 available
- Warranty: 10 years mechanical
