Description
The Yale 8800 Series PBR8861FL mortise lock trim pack delivers commercial-grade security for doors in offices, hospitals, schools and institutional buildings. Reinforced stainless steel deadbolt, vandal-resistant trim and ANSI/BHMA Grade 1 certification provide uncompromising strength and durability. Field-reversible latchbolt and quick lever handing simplify installation on any door orientation.
Fits standard 1-3/4" doors and orders up to 3-1/4" thick. Includes 6-pin brass cylinder with two keys; 7-pin upgrade available. UL/cUL fire-rated to 3 hours. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for handing confirmation, finish selection from 17 options, and expert installation guidance as an authorized Yale dealer.
Specifications
- ANSI/BHMA Certified A156.13, Series 1000, Grade 1
- UL/cUL Fire Rated: Up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; 3-1/4" to order
- Front: Bevel, free-floating, 1/8" standard adjustment
- Cylinders: Brass, 6-pin keyed-random with 2 keys (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" door, reversible
- Field Reversible Handing
- Available Finishes: 17
- Warranty: 10 year mechanical
