Description
The Yale 8800 Series PBR8867FL mortise lock trim pack delivers ANSI/BHMA Grade 1 security for commercial doors requiring heavy-duty performance and vandal resistance. Built with reinforced stainless steel deadbolt and field-reversible latchbolt, this lock solves durability demands in high-traffic applications while offering quick lever handing for easy installation on standard and thicker doors.
Compatible with 1-3/4" standard doors up to 3-1/4" thick, this trim pack includes a 6-pin keyed-random cylinder with two keys and reversible curved lip strike. Available in 17 finishes to match your facility's aesthetic. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert specification guidance and finish selection.
Specifications
- ANSI/BHMA Certification: A156.13 Series 1000, Operational Grade 1
- UL/cUL Fire Rating: Up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; up to 3-1/4" to order
- Front: Bevel, free-floating (flat to 1/8" standard bevel in 2")
- Cylinder: Brass, 6-pin keyed-random with two keys (7-pin available to order)
- Handing: Field reversible
- Strike: 1-1/4" curved lip for 1-3/4" door; reversible
- Finishes: 17 available
- Warranty: 10-year mechanical
- Windstorm Certification: Certified (refer to local codes)
