Description
The Yale 8800 Series mortise lock is a commercial-grade security solution designed for doors requiring ANSI/BHMA Grade 1 strength and reliability. Built with reinforced stainless steel deadbolts and heavy-duty, vandal-resistant trim, this lock serves hospitals, offices, schools and other high-traffic facilities that demand durability and tamper resistance.
This trim pack fits standard 1-3/4" doors with a 2-3/4" backset and features field-reversible handing for flexible installation. The lock includes brass, 6-pin cylinders with two keys and accommodates doors up to 3-1/4" thick by special order. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, compatibility and installation. Contact sales@edlocks.com or call 1-877-207-6067 for technical support.
Specifications
- ANSI/BHMA A156.13 Series 1000, Grade 1 certified
- UL/cUL fire rated up to 3 hours
- Windstorm certified per local codes
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Standard door thickness: 1-3/4"
- Maximum door thickness: 3-1/4" to special order
- Bevel front: free-floating, adjustable flat to 1/8" in 2"
- Cylinders: Brass, 6-pin keyed-random with 2 keys; 7-pin available
- Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" doors; other lengths special order
- Finishes: 17 available
- Warranty: 10 years mechanical
