Description
The Yale 8800 Series mortise lock delivers uncompromising strength and durability for commercial applications. Built with a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and ANSI/BHMA Grade 1 certification, this lock protects high-traffic doors in offices, retail, and institutional settings where security and longevity matter.
Quick lever handing and field-reversible latchbolt simplify installation on standard 1-3/4" doors; thicker doors to 3-1/4" available to order. Includes 6-pin keyed-random cylinder with two keys. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, keying options, and compatibility. Contact sales@edlocks.com or call 1-877-207-6067 for personalized support.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; up to 3-1/4" available to order
- Cylinder: Brass, 6-pin keyed-random with 2 keys (7-pin available)
- Front: Bevel front, free-floating adjustable
- Strikes: 1-1/4" curved lip for 1-3/4" door; other lengths available
- Mechanism: Stainless steel
- Reversibility: Field reversible handing
- Finishes: 17 finishes available
- Warranty: 10 year mechanical
- Windstorm: Certified
