Description
The Yale 8800 Series PNR8832FL mortise lock delivers ANSI/BHMA Grade 1 security for commercial doors. Built with reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim, this lock handles high-traffic entryways and institutional applications where durability and strength are non-negotiable. Field-reversible design and quick lever handing simplify installation.
Compatible with 1-3/4" standard door thickness (up to 3-1/4" available to order). Includes 6-pin keyed-random cylinder with two keys; 7-pin upgrade available. As an authorized Yale dealer, E.D. Locks provides expert guidance on specification, finish selection, and keying. Contact sales@edlocks.com or call 1-877-207-6067 for technical support and fast shipping on bulk orders.
Specifications
- Certification: ANSI/BHMA A156.13 Series 1000, Operational Grade 1; UL/cUL fire-rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (to 3-1/4" to order)
- Cylinder: Brass, 6-pin keyed-random with two keys (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths to order)
- Finishes: 17 available
- Mechanism: Stainless steel
- Field Reversible: Yes
- Warranty: 10 years mechanical
