Description
The Yale 8807FL 626 is a heavy-duty mortise lock built for commercial doors requiring ANSI/BHMA Grade 1 security and durability. Featuring a reinforced stainless steel deadbolt, vandal-resistant trim, and UL/cUL fire rating up to 3 hours, it solves the need for reliable access control in high-traffic or high-security applications.
This lock installs easily with quick lever handing and a field-reversible latchbolt, fitting standard 1-3/4" doors and thicker. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, keying, and compatibility. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for assistance choosing the right configuration for your project.
Specifications
- ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door thickness: 1-3/4" standard, to 3-1/4" thick doors available
- Fronts: Bevel front, free-floating, adjusts flat to 1/8" standard bevel
- Cylinders: 6-pin brass, keyed-random, two keys standard; 7-pin available
- Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" door standard
- Available in 17 finishes
- 10 year mechanical warranty
