Description
The Arrow RL11-SR-BSP-CS is a cylindrical lockset designed for multi-family housing and light commercial doors. This economical lock features cold-rolled steel construction with zinc dichromate finish for corrosion resistance, a guarded 1/2-inch brass latchbolt, and removable thru-bolts for easy installation and maintenance.
Compatible with standard 2-1/8-inch bore doors, 1-3/8-inch to 1-3/4-inch thick, with 2-3/8-inch or 2-3/4-inch backsets. Keyed with two brass keys and available in Arrow A keyway or Schlage CS. For expert guidance on keying, backset selection, or installation support, contact E.D. Locks at sales@edlocks.com or 1-877-207-6067. As an authorized Arrow dealer, we ensure you receive genuine hardware with full warranty support.
Specifications
- Brand: Arrow
- Model: RL11-SR-BSP-CS
- Type: Cylindrical Lock
- Bore: 2-1/8 inches (53.97mm)
- Backset: 2-3/8 inches (60.31mm) or 2-3/4 inches (69.85mm)
- Door Thickness: 1-3/8 inches to 1-3/4 inches (34.93mm to 44.45mm)
- Latchbolt: Brass, 1/2 inch (12.7mm) throw, guarded, UL Listed
- Latch Front: 1 inch x 2-1/4 inches (25.40mm x 57.15mm) for 2-3/8 backset or 1-1/8 inch x 2-1/4 inches for 2-3/4 backset
- Levers: Pressure cast zinc, 4-3/4 inches (120.65mm)
- Roses: Wrought brass, 3-3/8 inches (85.73mm) diameter
- Total Projection: 2-1/2 inches (63.5mm)
- Strike Options: 4-7/8 inch ANSI (123.83mm), 2-3/4 inch T strike (69.85mm), or 2-1/4 inch full lip strike (57.15mm)
- Cylinder: Solid brass, 6-pin
- Keyway: Arrow A standard; Schlage CS and competitive keyways available
- Keys: 2 brass keys included
- Handing: Non-handed
- Thru-bolts: Removable
- Finish: Zinc dichromate
- Warranty: Five Year Mechanical
- Packaging: 10 per case
