Description
The Arrow RL11 is a cylindrical lockset engineered for multi-family housing and light commercial doors. Its cold-rolled steel construction with zinc dichromate finish resists corrosion, while the guarded brass latchbolt delivers reliable security. Non-handed design and removable thru-bolts simplify installation across varied applications.
This lock fits standard 2-1/8" bore holes and accommodates doors 1-3/8" to 1-3/4" thick with backset options of 2-3/8" or 2-3/4". It comes keyed with 2 brass keys in Arrow "A" keyway; Schlage CS and other keyways available. Contact an authorized E.D. Locks dealer at sales@edlocks.com or 1-877-207-6067 for expert keying guidance and installation support.
Specifications
- Brand: Arrow
- Model: RL11-SR-BSP-IC
- Type: Cylindrical Lock
- Bore Size: 2-1/8" (53.97mm)
- Backset: 2-3/8" (60.31mm) or 2-3/4" (69.85mm)
- Door Thickness: 1-3/8" to 1-3/4" (34.93mm to 44.45mm)
- Latchbolt: Brass, 1/2" (12.7mm) throw, UL Listed, guarded
- Latch Front: 1" x 2-1/4" (2-3/8" backset) or 1-1/8" x 2-1/4" (2-3/4" backset)
- Lever: Pressure cast zinc, 4-3/4" (120.65mm) length
- Rose: Wrought brass, 3-3/8" (85.73mm) diameter
- Total Projection: 2-1/2" (63.5mm) from door face
- Strike Options: 4-7/8" ANSI (123.83mm), 2-3/4" T strike (69.85mm), or 2-1/4" full lip strike (57.15mm)
- Cylinder: Solid brass, 6-pin
- Keyway: Arrow "A" standard; Schlage CS and competitive keyways available
- Keys Included: 2 brass keys
- Handing: Non-handed
- Thru-bolts: Removable (standard)
- Material: Cold-rolled steel with zinc dichromate finish
- Warranty: Five Year Mechanical
- Packaging: 10 per case
