Description
SL7160 Series with Two Step Rose is Ideal for Retrofitting
UL listed, ADA approved Grade 2 barrier-free leversets are ready for all ADA and other needs in passage, privacy, storeroom, classroom and dummy functions, in addition to entry models. The customer may provide the lock cylinder and key. Leversets meet ANSI A156.2 Series 4000 Grade standards and more than fulfill ADA requirements. The ANSI Series 4000 standard exceeds 400,000 operating cycles.
S. Parker leverset features and functions include:
- Two step rose
- Cold rolled steel housing
- Reversible, non-handed
- Fits doors from 1 3/8" to 2" thick
- 2 3/4" backset UL listed latch bolt. Standard for all functions
- 1 1/4" x 4 7/8" ANSI strike. Standard for all leversets, all functions.
- 6 pin solid brass SC-1 keyway, ILCO #1145, keyed to 5 pins
- Wide choice of finishes (US 26D, 26, 3, 10B)
- Special keying available (Master and Grand Master)
- Each lever works independently of the other
- Dead locking latch on all keyed leversets
- 2 nickel silver keys
- Separate lever spring mechanisms help prevent sag
- 1/2" throw solid brass latch-bolt, UL listed, three hour fire rated
- Full 5" long handles on all levers in all functions
- Screws are concealed for the greatest security and appearance
- Accepts Lori 1539/1590; ILCO 7035; DOM 1x5HT Medeco 20-200A1 or ASSA cylinder plugs
- Convertible Posts
- 3 3/8" Diameter Roses
