Description
The Securitron SAM is a concealed electromagnetic lock delivering 1200 lbs. of holding force for high-security applications. Designed for facility managers and integrators, it mounts fully hidden within wood, steel, or aluminum doors in any position—top, side, or bottom—making it ideal for swing-through and sliding doors where aesthetics and security matter.
The SAM operates at dual voltage (12VDC or 24VDC) with no field adjustment required, features a patented instant release circuit to eliminate residual magnetism, and includes ten feet of jacketed conductor for flexible installation. All ferrous surfaces meet MIL specification plating standards. For proper sizing, compatibility with your access control system, and MagnaCare lifetime warranty registration, contact our experts at sales@edlocks.com or 1-877-207-6067.
Specifications
- Holding Force: 1200 lbs. (544 kg)
- Current Draw: 320mA at 12VDC; 170mA at 24VDC
- Operating Temperature: -40 to +140F (-40 to +60C)
- Conductor: Ten feet (3.05m) jacketed, stranded
- Features: Patented instant release circuit, fully sealed electronics, UL Listed, MagnaCare lifetime replacement warranty
