Description
The Falcon T101S Q 625 is a Grade 1 cylindrical lock built for high-traffic institutional doors. Its heavy-duty construction with compression springs exceeds ANSI/BHMA testing standards, making it ideal for schools, hospitals, and government buildings where durability and reliable security are non-negotiable.
This lock accepts any manufacturer's cylinder and features removable cylinders for quick re-keying without door removal, simplifying retrofits and maintenance. As an authorized Falcon dealer, E.D. Locks provides expert configuration guidance and free shipping over $450. Contact our team at sales@edlocks.com or 1-877-207-6067 for backset, handing, keyway, and cylinder options tailored to your door and security needs.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard (thin door adapter kit available)
- Backset: 2-3/4" standard (2-3/8" available; 5" with link)
- Bolt Projection: 9/16" standard (3/4" available)
- Cylinder: 6-pin chambers, pinned in 5 (6 or 7-pin available)
- Keyway: G keyway standard (A keyway standard on I/C cores; optional keyways available)
- Interchangeable Core: SFIC and large format available
- Material: Brass or cold-formed steel, zinc-plated and dichromated; stainless steel springs
- Trim: Heavy wrought brass or bronze roses; pressure-cast levers
- Latch: UL listed, 2-1/4" x 1-1/8" faceplate with square corners
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip
- Handing: Non-handed
- Keys: Two nickel silver keys furnished standard
