Description
The Falcon T511BD D 613 is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic and heavy-abuse institutional applications. Non-handed design accepts any manufacturer's cylinder with easy removability for quick re-keying, making retrofit installations simple and cost-effective for building managers and facility directors.
Standard door thickness is 1-3/4" to 2-1/8" with adjustable backset options (2-3/8" or 2-3/4"). Brass and stainless steel construction with zinc-plated, dichromated finish resists rust. For compatibility questions, custom backsets, or interchangeable core options, contact our authorized dealer experts at sales@edlocks.com or 1-877-207-6067 for free guidance.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard
- Backset: 2-3/4" standard; 2-3/8" available
- Bolt Projection: 9/16" standard; 3/4" available
- Latch Faceplate: 2-1/4" x 1-1/8" standard
- Cylinders: 6-pin (5 pinned) standard; 6, 7-pin or SFIC available
- Keyway: G standard (conventional); A standard (I/C core)
- Handing: Non-handed
- Material: Brass, cold-formed steel, stainless steel springs
- Finish: Zinc plated and dichromated
- Keys: Two nickel silver keys included
- Strike: 4-7/8" x 1-1/4" ANSI curved lip
