Description
The Falcon T511BD Q 605 is an extra heavy-duty Grade 1 cylindrical lock built for high-traffic and heavy-abuse institutional applications. Non-handed design with removable cylinder for easy re-keying makes retrofitting existing buildings straightforward. Compression spring construction exceeds ANSI/BHMA Grade 1 testing requirements, delivering reliable security at competitive pricing.
Standard door thickness is 1-3/4" to 2-1/8"; thin door adapter kits are available for custom needs. Cylinders are drilled with 6-pin chambers (pinned in 5, with 6-pin or 7-pin options available). Interchangeable core designs support small and large formats. Our authorized dealer team at E.D. Locks can guide you through cylinder options, keying specifications, and installation details. Contact sales@edlocks.com or call 1-877-207-6067 for expert assistance.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard (thin door adapter kit available)
- Backset: 2-3/4" standard (2-3/8" available; 5" backset link available)
- Bolt Projection: 9/16" standard (3/4" option available)
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners standard
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip
- Cylinder Pinning: 6-pin chambers, pinned in 5 standard (6-pin or 7-pin available)
- Keyways: G keyway standard on conventional cylinders, A keyway on I/C core cylinders
- Material: Brass and cold-formed steel with zinc plating and dichromate finish; stainless steel springs
- Handing: Non-handed
- Keys: Two nickel silver keys furnished standard
