Description
The Falcon T Series T561CP6D is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic institutional and commercial applications. Its compression spring construction exceeds ANSI/BHMA Grade 1 testing requirements, making it ideal for facilities demanding durability and reliability in demanding environments.
This lock fits standard 1-3/4" to 2-1/8" doors with a 2-3/4" backset and features a removable, rekeying-ready cylinder assembly drilled with 6-pin chambers (pinned in 5, upgradeable to 6 or 7-pin at no cost). Interchangeable core options are available. Contact our experts at sales@edlocks.com or 1-877-207-6067 for help selecting the right configuration, thin door adapters, or alternative backsets for your facility.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard (thin door adapter kit A30775-000-00 available)
- Backset: 2-3/4" standard (2-3/8" available; 5" backset link A22161-005-10 available)
- Latch Projection: 9/16" standard (3/4" projection available)
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners
- Cylinder: 6-pin chambers, pinned in 5 (6 or 7-pin available)
- Keyway: G keyway standard on conventional cylinders, A keyway on interchangeable core cylinders
- Keys: Two nickel silver keys furnished standard
- Material: Brass or cold formed steel with zinc plating and dichromate finish; stainless steel springs
- Interchangeable Core: Available in small format (SFIC) and large format
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip
- Handing: Non-handed
