Description
The Falcon T561LD D 625 is an extra heavy-duty Grade 1 cylindrical lock built for high-traffic and heavy-abuse institutional applications. Non-handed design with removable cylinder for quick re-keying makes retrofitting existing buildings simple and cost-effective. Compression spring construction exceeds ANSI/BHMA Grade 1 testing requirements.
Standard for 1-3/4" to 2-1/8" doors with 2-3/4" backset; thin door adapters and alternate backsets available. Cylinder housings and plugs machined from solid brass with stainless steel springs for rust resistance. Interchangeable core options support small and large format designs. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for specification verification, handing options, and keying assistance.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard
- Backset: 2-3/4" standard (2-3/8" available; 5" with link A22161-005-10)
- Bolt Projection: 9/16" standard
- Latch Faceplate: 2-3/4" x 1-1/8" with square corners
- Cylinder: 6-pin chambers, pinned in 5 (6 or 7-pin available)
- Keyway: G keyway standard (A keyway on interchangeable core)
- Cylinder Material: Solid brass housing and plug
- Spring Material: Stainless steel (springs); phosphor bronze (cylinder)
- Finish: Zinc plated and dichromated for rust resistance
- Handing: Non-handed
- Keys: Two nickel silver keys standard
- Strike: 4-7/8" x 1-1/4" ANSI curved lip
- UL Listed: Yes
