Description
The Falcon TP50S D 605 is a commercial mortise lock engineered for high-traffic office, hospital, and educational facilities. This durable MA Series lock combines security with reliability, featuring a two-piece stainless steel latch bolt and a 1-inch throw deadbolt with saw-resistant rollers. It solves the need for tough, dependable access control in demanding environments.
The TP50S accommodates door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset and supports interchangeable SFIC cores for quick re-keying without door removal. It meets ANSI/BHMA 156.13 Series 1000 and carries a UL 3-hour A label. As an authorized Falcon dealer, E.D. Locks provides expert guidance on cylinder options, keyways, and electrified configurations. Contact our team at sales@edlocks.com or 1-877-207-6067 for specifications and installation support.
Specifications
- Brand: Falcon (Allegion)
- Model: TP50S D 605
- Lock Type: Mortise
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Hubs: Hardened steel
- Cylinder Options: 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G keyway (standard cylinder), A keyway (I/C cylinder)
- Handing: Right hand standard, left hand optional, reversible
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for bevel
- Strike: Brass or stainless steel, non-handed, ANSI A115.1 compliant
- Electrified: Available 12 or 24 VDC
- Cylinders: Solid brass with two nickel silver keys standard
- Certification: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
