Description
The Falcon TP50S Q 605 is a high-performance mortise lock engineered for commercial environments including offices, hospitals, and educational facilities. Built to withstand constant use, this MA Series lock delivers dependable security with an interchangeable core for quick re-keying and cross-manufacturer SFIC compatibility, solving the need for durable, maintainable access control.
Compatible with standard door thicknesses of 1-3/8" to 2-1/2" and a 2-3/4" backset, this lock features a 1" throw deadbolt with saw-resistant rollers and mechanical anti-friction latch. Right-hand configuration is standard; left-hand and field reversal are available. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying options, electrified functions, and installation support.
Specifications
- Brand: Falcon
- Model: TP50S Q 605
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Deadbolt Throw: 1"
- Latch Bolt Projection: 3/4"
- Deadbolt: Stainless steel with 13/16" hardened steel saw-resistant rollers
- Cylinders: Solid brass, 5, 6 or 7-pin standard; 6 or 7-pin on interchangeable core
- Keyways: G keyway standard, A keyway on I/C cylinder
- Handing: Right hand standard, left hand optional, field reversible
- Faceplate: 1-1/4" x 8" brass or stainless steel, adjustable for bevel
- ANSI/BHMA: Meets 156.13, Series 1000
- UL: 3 hour A label
- Electrified: Available 12 or 24 VDC
- Keys: Two nickel silver keys included
