Description
The Falcon TP50S S 613 is a heavy-duty mortise lock built for commercial environments like offices, hospitals, and educational facilities. Featuring a two-piece stainless steel latch bolt with mechanical anti-friction design and a 1" throw dead bolt with saw-resistant rollers, this lock delivers dependable security and withstands constant use. The interchangeable core allows quick re-keying without removing the lock body.
The TP50S S 613 fits standard door thicknesses from 1-3/8" to 2-1/2" and accommodates 2-3/4" backsets. It is SFIC-compatible with cores from other manufacturers and meets ANSI/BHMA 156.13 Series 1000 and UL 3-hour A label standards. For expert advice on keying options, handing, or electrified configurations, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: Falcon
- Model: TP50S S 613
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: 3/4" projection, two-piece stainless steel with mechanical anti-friction
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers (13/16" diameter)
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G keyway standard (standard cylinder), A keyway standard (interchangeable core)
- Hubs: Hardened steel
- Handing: Right hand standard, left hand optional, reversible in field
- Faceplate: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, non-handed, meets ANSI A115.1
- Electrified: Available 12 or 24 VDC
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
- Furnished: Two nickel silver keys standard
