Description
The Falcon TP55E Q 626 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. It combines security with durability, featuring a stainless steel latch bolt with mechanical anti-friction design and a 1-inch deadbolt with saw-resistant rollers. The interchangeable core (SFIC-compatible) enables quick re-keying without removing the lock body, making it ideal for retrofit and maintenance-friendly applications.
This lock accommodates standard door thicknesses from 1-3/8" to 2-1/2" and features cold-formed steel construction with 8-32 bind-resistant trim inserts. It meets ANSI/BHMA 156.13 Series 1000 and carries a 3-hour UL A label. Right-hand handing is standard; left-hand and field-reversible options are available. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert configuration guidance and authorized dealer support.
Specifications
- Brand: Falcon
- Model: TP55E Q 626
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold-formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplate: 1-1/4" x 8" brass or stainless steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin IC
- Keyways: G (standard cylinder), A (IC cylinder)
- Handing: Right-hand standard, left-hand optional, field-reversible
- Electrified: Available 12 or 24 VDC
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
- Includes: Two nickel silver keys
