Description
The Falcon TP60C D 630 is a mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines affordability with durability, featuring a two-piece stainless steel latch bolt and a 1-inch deadbolt with saw-resistant rollers to handle constant use without compromise.
The TP60C D 630 accommodates door thicknesses from 1-3/8 inch to 2-1/2 inch and features an interchangeable core (SFIC-compatible) for quick re-keying and maintenance flexibility. Installation is straightforward with adjustable armored faceplates and bind-resistant trim. As an authorized Allegion dealer, E.D. Locks provides expert guidance on keying options, electrified configurations, and field reversibility. Contact sales@edlocks.com or call 1-877-207-6067 for application support.
Specifications
- Brand: Falcon
- Model: TP60C D 630
- Door Thickness: 1-3/8 inch to 2-1/2 inch
- Backset: 2-3/4 inch only
- Case: Cold formed steel, zinc dichromate plated, 0.090 inch thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Latch Bolt: Two-piece stainless steel, 3/4 inch projection
- Deadbolt: 1 inch throw, stainless steel with saw-resistant rollers
- Faceplate: 1-1/4 inch x 8 inch, adjustable for door bevel
- Cylinders: Solid brass, 5, 6, or 7-pin available
- Standard Keyway: G keyway on standard cylinder; A keyway on I/C cylinder
- Electrified: Available in 12 or 24 VDC
- Certification: ANSI/BHMA 156.13 Series 1000; UL 3 hour A label; ANSI A115.1 strike
- Included: Two nickel silver keys
