Description
The Falcon TP60C A 630 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. Its MA Series design combines security with dependability, featuring a mechanical anti-friction latch bolt and a 1-inch throw dead bolt with saw-resistant rollers. This lock handles constant use without compromise.
The TP60C accommodates door thickness from 1-3/8" to 2-1/2" and features an interchangeable core (A keyway) for quick re-keying and SFIC compatibility. Standard 2-3/4" backset with cold-formed steel construction and optional electrified functions (12/24 VDC) available. Meets ANSI/BHMA 156.13 Series 1000 and UL 3-hour A label. Contact an E.D. Locks authorized dealer at sales@edlocks.com or 1-877-207-6067 for expert specification guidance and keying assistance.
Specifications
- Brand: Falcon
- Model: TP60C A 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 6 or 7-pin interchangeable core
- Keyway: A keyway (I/C standard)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for bevel
- Electrified Functions: 12 or 24 VDC available
- ANSI/BHMA: 156.13, Series 1000
- UL: 3 hour A label
