Description
The Falcon TP85E A 626 is a heavy-duty mortise lock designed for commercial environments including offices, hospitals, and educational facilities. Its MA Series construction delivers dependable security and withstands constant use without fail. The interchangeable core enables quick re-keying and works with SFIC products from other manufacturers, making maintenance and facility management simpler.
This lock accommodates door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset and meets ANSI/BHMA 156.13 Series 1000 standards. It's reversible in the field for flexible installation. As an authorized Allegion dealer, E.D. Locks provides expert support for specification, keying, and installation guidance. Contact our team at sales@edlocks.com or 1-877-207-6067 for assistance with your project.
Specifications
- Brand: Falcon
- Model: TP85E A 626
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Cylinders: Solid brass, 5, 6, or 7-pin available (standard); 6 or 7-pin available (interchangeable core)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Electrified Functions: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3 hour A label
- Handing: Right hand standard; left hand optional, reversible in field
