Description
The Falcon TP85E H 626 is a mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. This MA Series lock delivers dependable security and durability to withstand constant use without failure, making it ideal for retrofit projects requiring quick re-keying and minimal downtime.
The TP85E H 626 features an interchangeable core compatible with SFIC products, accommodates door thicknesses from 1-3/8" to 2-1/2", and is reversible in the field for flexible installation. As an authorized Allegion dealer, E.D. Locks provides expert configuration guidance and support at sales@edlocks.com or 1-877-207-6067 to ensure proper keying and setup for your project.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional; reversible in field
- Cylinders: Solid brass, 5, 6 or 7-pin available on standard cylinders; 6 or 7-pin on interchangeable core
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, non-handed
- Electrified Functions: Available in 12 or 24 VDC
- ANSI/BHMA: Meets ANSI/BHMA 156.13, Series 1000
- UL: 3 hour A label
- Supplied with: Two nickel silver keys
