Description
The Falcon TP95E A 626 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. This MA Series lock delivers dependable security and withstands constant use without fail, featuring an interchangeable core for quick re-keying and compatibility with SFIC products from other manufacturers.
The lock accommodates door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset and meets ANSI/BHMA 156.13 Series 1000 standards. It's reversible in the field and available in right or left hand configurations. As an authorized Falcon dealer, E.D. Locks provides expert guidance on installation, keying options, and electrified functions. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- Brand: Falcon
- Model: TP95E A 626
- Lock Type: Mortise
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Cylinder: Solid brass, 5, 6 or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G (standard cylinder), A (interchangeable core)
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Electrified: Available 12 or 24 VDC
- ANSI/BHMA: 156.13, Series 1000
- UL: 3 hour A label
