Yale's 3000 Series surface-mounted door closer combines proven reliability with professional appearance for commercial and institutional buildings. Designed for high-traffic entrances, this architectural closer offers adjustable spring tension (sizes 1-6), independent control of latch, sweep and backcheck functions, and tri-packed mounting flexibility to solve installation challenges on virtually any door frame configuration.
The 3000 Series features a cast aluminum body, rack and pinion mechanism, and staked valves for long-term durability. Compatible with regular arm, top jamb, and parallel arm mounting options; non-handed for left or right swing doors. For proper sizing, installation guidance, and finish selection, contact our authorized dealer experts at sales@edlocks.com or 1-877-207-6067 to ensure optimal performance on your specific application.
Specifications
- Cast aluminum body
- Adjustable spring sizes 1 through 6
- Tri-packed mounting: regular arm, top jamb, parallel arm
- Non-handed (works left or right swing)
- Staked valves
- Rack and pinion design
- Piston diameter: 1-1/4 inch (32mm)
- Pinion journal diameter: 5/8 inch (16mm)
- Separate, independent latch, sweep, and backcheck intensity valves
- Projection: 2-1/8 inch (54mm) with standard covers
